Hybrid vacuum-tube Active Book-shelf Speaker
DS25
DS25
modern and vintage harmonize design
Modern and vintage harmonize design
The design motive from the classic gramophone. Horn type tweeter, retro speaker grill design and the amplifier with vintage vacuum tube. This design gives you the special and retro romantic feelings and bring it back to today’s life.
modern
Design
vintage
Design
motive
Design
motive
Design
The design motive from the classic gramophone
Customized hybrid vacuum tube
VACUUM TUBE Customized hybrid vacuum tube
The quality of LANCHIYA® customized vacuum tubes for the new hybrid amplifiers is the same as what the military industrial enterprise requests. We take the advantage of the even harmonics to enhance the dynamic range and the frequency response of the sound. The tubes can make the sound mellow and charming. The life of the tubes is about 50,000 hours.
Advanced DSP sound technology E.A.I bass technology
EAI / iEAI Advanced DSP sound technology E.A.I bass technology
LANCHIYA®EAI™ (Electronics&Acoustics Integration) chip module to make the electronics, speaker drivers and housing structure match each other perfectly so that the whole speaker system can perform at its best status and produce the best sound. With the help of DSP to correct the input signal in a nondestructive way , the whole speaker system can perform beyond its physical limitation.
Experience our audio technology taken to new heights with E.A.I & Digital Sound Processing (DSP) Fine-tuned for perfection maximum power generated from its two 0.8” silk dome tweeters, two 2 ¼” active wide frequency response speaker driver units.
DS25
modern and vintage harmonize design
Stable wireless connection & NFC easy pairing
Bluetooth Version 4.2 + EDR/A2DP (CSR Solution)
AUX 3.5mm Stereo AUX input port
Support aptX solution
AUX in for additional multimedia audio sources.
Bluetooth™ CSR™ apt X®to transmit 16 bits 44.1kHz and
max 16 bits 48kHz CD quality music.
RIAA Standard design Professional Phono port
(RIAA standard design) Professional Phono port for making LP’s bass balance
4 layers Ferrite magnet
100% paper-pulp speaker cone design
Minimum diffraction horn type tweeter
Conex damper
40W RMS (T.H.D 1%) I.E.C STANDARD
28kHz super tweeter
3Way 3Speaker & 2ch stereo type/ Total 40W RMS Output power ( I.E.C Standard ) made with advanced Sound Technology through Research & Development.
Paper-pulp speaker unit design has been around for decades. However, through many years of R&D testing and improvements, LANCHIYA® a developed a precise special formula to ensure LANCHIYA® 100% paper-pulp design has achieved the most advantageous solution in the industry.
LANCHIYA®’s professional design and engineering team has worked on Audio field for 36years. We design, develop, research, and produce every speaker unit from beginning to the end to guarantee perfect quality control.
* Mouse over view
TAIKO BASS BOOSTER™ design
Minimum diffraction horn type tweeter
2¼"Speaker
Driver unit
28kHz super tweeter
Tweeter tube for separate space
100% paper-pulp speaker cone design
PMCM enclosure
2¼"Speaker
Driver unit
Cross-over network
Advanced 2nd generation T.B.B Sound technology
TAIKO BASS BOOSTER™ (Invention patent)
TAIKO Bass Booster™ is a low frequency multiplication technology which is painstakingly invented by LANCHIYA®'s R&D team after seven years' reseach and study. It's a revolutionary and innovative new technology of electro acoustics,which combines LANCHIYA®'s patent technology of double resonators and EAI™(Electronics Acoustics Integration System) It can multiply the power of low frequency in a small speaker housing. Even the volume is very small, it still can make the speaker produce the clear, powerful and elastic bass. This technology reflects LANCHIYA®'s persevering spirit of pursueing the Hi-Fi sound quality.
The tweeter used to reach to 15-20kHz. But Lanchiya R&D team is willing to make it reach up to 28kHz with their 36 years experience. The advanced silk dome tweeter which imported from Japan will be used for the amplifier. The perfect tweeter can be presented based on the perfect match by the tubes and the amplifier.
Minimum diffraction horn type tweeter for natural sound reproduction. We take the advantage of the horn type structure to enhance high frequency up to 28KHz. Make the sound levels and the sound field more clear. The horn type tweeter can reproduce high frequency with more fidelity and decrease the sound diffraction.
3Way 3Speaker design and professional cross-over network design
two 0.8” silk dome tweeters, two 2 ¼” active wide frequency response speaker driver units, two 2 ¼” active bass frequency response speaker driver units with professional cross-over network design
Headphone amplifier
Built-in High performance vacuum tube headphone amplifier
The headphone amplifier can drive the headphone impedances from 32Ω to 600Ω by the advanced automatic impedance matching system. Its power is 7W. It can support all of the audio formats by the high performance of the hardware decoder. It’s compatible with DSD256, DSD128 and DSD64. Including PCM 32bit 384kHz. The vacuum tubes are used for adjusting the sound. The external sound output and the internal decode input can be freely switched.
Intuitional user control interface
A rotating knob for functional control ( OFF- Bluetooth-AUX-Phono-PC USB) and a rotating knob for volume control. Aluminium control switches for the sound effect function and the headphone amplifier select.It is about the useful and intuitional user control interface design.
PMCM Enclosure
High Polymer Plasticity Micro Crystal Material
Enclosure with PMCM (Plasticity Micro Crystal Material) acoustic material coated with Lanchiya® Matt finish coationg paint. Nice workmanship and no sticky forever. Good structural strength prevents from unnecessary resonance.
Matt finish coating
High class surface painting technology
Specially developped furface treatment Floss Spray Paint marked by sand feeling and long life. Comparing with rubber paint, no sticky for ever.
SPECIFICATION
COLOR OPTION
Dark gray
Matt finish coating
Black
Matt finish coating
Milky white
Matt finish coating
Download
DS25 Presentation
