A masterpiece will speak any way for itself.

Hybrid vacuum-tube speaker system

DS55


Modern and vintage harmonize design

The design motive from the classic gramophone. Horn type tweeter, retro speaker grill design and the amplifier with vintage vacuum tube. This design gives you the special and retro romantic feelings and bring it back to today’s life.

VACUUM TUBE Customized hybrid vacuum tube


The quality of LANCHIYA® customized vacuum tubes for the new hybrid amplifiers is the same as what the military industrial enterprise requests. We take the advantage of the even harmonics to enhance the dynamic range and the frequency response of the sound. The tubes can make the sound mellow and charming. The life of the tubes is about 50,000 hours.

Operating principle.png

EAI / iEAI Advanced DSP sound technology E.A.I bass technology

LANCHIYA®EAI™ (Electronics&Acoustics Integration) chip module to make the electronics, speaker drivers and housing structure match each other perfectly so that the whole speaker system can perform at its best status and produce the best sound.  With the help of DSP to correct the input signal in a nondestructive way , the whole speaker system can perform beyond its physical limitation.

Experience our audio technology taken to new heights with E.A.I & Digital Sound Processing (DSP) Fine-tuned for perfection maximum power generated from its 0.8” silk dome tweeters, 4” active wide frequency response speaker driver units.

3.5mm AUX.png

Stable wireless connection & NFC easy pairing

Bluetooth Version 4.2 + EDR/A2DP (CSR Solution)

Support aptX solution

Bluetooth™ CSR™ apt X®to transmit 16 bits 44.1kHz and max 16 bits 48kHz CD quality music.

External active sub-woofer output port

Connect with external active sub-woofer for the stronger bass sound

AUX 3.5mm Stereo AUX input port

AUX in for additional multimedia audio sources.


RIAA Standard design Professional Phono port

(RIAA standard design) Professional Phono port for making LP’s bass balance

LANCHIYA MK40_INTRO_07.png
기록 헤드 B & W
기록 cleaning_2
산업 디자이너
엔지니어링 스케치
컴퓨터 회로 보드 매크로
헤드폰

36years.

LANCHIYA®’s professional design and engineering team has worked on Audio field for 36years. We design, develop, research, and produce every speaker unit from beginning to the end to guarantee perfect quality control.

DS55

professional audio design


4 layers Ferrite magnet

paper cone.png

100% paper-pulp speaker cone design

Flower horn.png

Minimum diffraction horn type tweeter

Conex damper.png

Conex damper

RMS 80W.png

80W RMS (T.H.D 1%) I.E.C STANDARD

* 100W RMS (T.H.D 10%)

28kHz Tweeter.png

28kHz super tweeter

3Way 3Speaker & 2ch stereo type. Total 80W RMS Output power 1%T.H.D ( I.E.C Standard )  made with advanced Sound Technology through Research & Development.

Paper-pulp speaker unit design has been around for decades.  However, through many years of R&D testing and improvements, LANCHIYA®  a developed a precise special formula to ensure LANCHIYA®  100% paper-pulp design has achieved the most advantageous solution in the industry.


The tweeter used to reach to 15-20kHz. But Lanchiya R&D team is willing to make it reach up to 28kHz with their 36 years experience. The advanced silk dome tweeter which imported from Japan will be used for the amplifier. The perfect tweeter can be presented based on the perfect match by the tubes and the amplifier.

Minimum diffraction horn type tweeter for natural sound reproduction. We take the advantage of the horn type structure to enhance high frequency up to 28KHz. Make the sound levels and the sound field more clear. The horn type tweeter can reproduce high frequency with more fidelity and decrease the sound diffraction.


3Way 3Speaker design and professional cross-over network design

two 0.8” silk dome tweeters, four 4” active wide frequency response speaker driver units with professional cross-over network design


Headphone amplifier

Built-in High performance vacuum tube headphone amplifier

The headphone amplifier can drive the headphone impedances from 32Ω to 600Ω by the advanced automatic impedance matching system. Its power is 7W. It can support all of the audio formats by the high performance of the hardware decoder. It’s compatible with DSD256, DSD128 and DSD64. Including PCM 32bit 384kHz. The vacuum tubes are used for adjusting the sound. The external sound output and the internal decode input can be freely switched.


Intuitional user control interface

A rotating knob for functional control ( OFF- Bluetooth-AUX-Phono-PC USB) and a rotating knob for volume control. Aluminium control switches for the sound effect function and the headphone amplifier select.It is about the useful and intuitional user control interface design.


PMCM Enclosure

High Polymer Plasticity Micro Crystal Material

Enclosure with PMCM (Plasticity Micro Crystal Material) acoustic material coated with Lanchiya® Matt  finish coationg paint. Nice workmanship and no sticky forever. Good structural strength prevents from unnecessary resonance.


Matt finish coating

High class surface painting technology

Specially developped furface treatment Floss Spray Paint marked by sand feeling and long life. Comparing with rubber paint, no sticky for ever.

SPECIFICATION

LANCHIYA DS55 INTRO_18.png

COLOR OPTION


Black

Matt finish coating

Dark gray

Matt finish coating

Milky white

Matt finish coating

친구 파티
화려한 디너 파티
헤드폰
가족 크리스마스 트리

Download
DS55 Presentation
